190-01115-01 G3X/G3X Touch Installation Manual - GSA 28 Installation

Rev. AC Page 17-10

17.5.2.6 GSA 28 Mounting Kits

Garmin currently provides the mounting kits listed in Table 17-8 for the GSA 28 Servo:

The “generic” kits listed in Table 17-8 (011-02952-00, -01, & -02) are not specific to any airframe. The

airframe specific kits (GPN 011-02952-10 through -16) are for use with the specified experimental aircraft.

The contents of each kit as well as specific instructions for their use are detailed in the figures listed in

Table 17-8.

Table 17-8 Mounting Kits

Garmin P/N Description

Mounting

Bracket

Included

Install Manual

Figures

011-02952-00 Sub-Assy, GSA 28 Mounting Kit, Generic, Push-Pull No 17-8.7

011-02952-01 Sub-Assy, GSA 28 Mounting Kit, Generic, W/Bracket Yes 17-8.8

011-02952-02 Sub-Assy, GSA 28 Mounting Kit, Generic, Capstan No 17-8.4

011-02952-10 Sub-Assy, GSA 28 Mounting Kit, RV-6 Roll Yes

17-9.1, 17-9.1,

17-9.1

011-02952-11 Sub-Assy, GSA 28 Mounting Kit, RV-4/8 Pitch Yes

17-10.1, 17-10.1,

17-10.1

, 17-10.1

011-02952-12 Sub-Assy, GSA 28 Mounting Kit, RV-7/8/10 Roll Yes 17-11.1, 17-11.1

011-02952-13 Sub-Assy, GSA 28 Mounting Kit, RV-9 Roll Yes 17-12.1, 17-12.1

011-02952-14 Sub-Assy, GSA 28 Mounting Kit, RV-6/7/9 Pitch Yes 17-13.1, 17-13.1

011-02952-15 Sub-Assy, GSA 28 Mounting Kit, RV-10 Pitch Yes 17-14.1, 17-14.1

011-02952-16 Sub-Assy, GSA 28 Mounting Kit, RV-10 Yaw Yes

17-15.1, 17-15.1

17-15.1
