190-01115-01 G3X/G3X Touch Installation Manual - Engine/Airframe Sensor Installation
Rev. AC Page 23-8
Rotax 914 Sensors - Order all sensors in the Rotax 912 sensor kit (K00-00514-00) except the
494-30004-03 fuel pressure sensor (use UMA N1EU07D differential fuel pressure sensor instead).
Jabiru Sensors - See Section 32
for Jabiru engine sensor wiring information.
Table 23-6 Rotax 914 Sensors
Sensor Type Details/Part Number
RPM
Use Rotax tachometer output along with external components from
011-02348-00 kit
Manifold pressure Use Kavlico P4055-30A-E4A (494-30004-01)
Oil pressure Use Rotax-supplied sensor
Oil temperature Use Rotax-supplied thermistor
Exhaust gas temperature Use Type K thermocouple (494-70001-00)
Cylinder head temperature Use Rotax-supplied thermistor
Fuel pressure Use UMA N1EU07D differential fuel pressure sensor
Fuel flow Use EI FT-60 (494-10001-00) or Floscan 201B-6
Table 23-7 Jabiru Sensors
Sensor Type Details/Part Number
RPM Use Jabiru tachometer output from alternator
Manifold pressure Use Kavlico P4055-30A-E4A (494-30004-01)
Oil pressure
Use Jabiru-supplied VDO pressure sensor, or Kavlico P4055-150G-E4A
(494-0004-00)
Oil temperature
Use Jabiru-supplied VDO 50-150°C thermistor, or any compatible RTD
such as UMA 1B3XR series
Exhaust gas temperature Use Jabiru-supplied Type K thermocouples
Cylinder head temperature Use Jabiru-supplied Type J thermocouples
Fuel pressure Use Kavlico P4055-15G-E4A (494-30004-03)
Fuel flow Use EI FT-60 (494-10001-00) or Floscan 201B-6
