Garmin G3X Touch Installation Manual

190-01115-01 G3X/G3X Touch Installation Manual - GPS/XM Antenna Installation
Rev. AC Page 22-37
Figure 22-38 GA 57X Installation Drawing
.25 6.4
2.35 59.7
2X 0
2X 1.600 40.64
2X 0
1.000 25.40
2.350 59.69
2X 3.300 83.82
.70 17.8
.65 16.5
2X .800 20.3
.49 12.3
XM
GPS BNC CONNECTOR
TNC CONNECTOR
FORWARD
4.70 119.4
MOUNTING CUTOUT
FORWARD
011-01032-00
ANTENNA OUTLINE
.220 5.594X
2X
.750 .625
19.05 15.88
TORQUE 20 TO 25 in-lbs
253-00138-00
1. DIMENSIONS: INCHES[mm]
FORWARD
4X 211-60212-20 #10-32 PHP x 1.00[25.4]
MOLDED GASKET
NOTES:
AIRCRAFT SKIN
011-01032-10 GA 57X GPS/XM ANTENNA
FABRICATE AND INSTALL DOUBLER PLATE AS REQUIRED TO COMPLY WITH APPLICABLE AIRWORTHINESS REGULATIONS
.80 20.2
73.72.90
.60 15.2

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
