190-01115-01 G3X/G3X Touch Installation Manual - GAD 29 Installation
Rev. AC Page 4-3
4.6 Outline and Installation Drawings
Figure 4-2 GAD 29 Outline Drawing
6.100
154.94
1.479 37.57
.100 2.54
.040 1.02
TYPICAL THICKNESS
BENEATH FASTENER HEAD
2X 2.352
59.74
2X 5.600
142.24
2X .250
6.35
2X .369
9.37
5.539
140.68
WITH CAN TERMINATOR
5.095[129.41]
WITHOUT CAN TERMINATOR
5.095
129.41
2.950 74.93
CENTER OF GRAVITY
3.090 78.49
3.235 82.17
.675
17.15
CENTER OF GRAVITY
2.350 59.69
CENTER OF GRAVITY
NOTES:
DIMENSIONSIN INCHES [mm]. METRIC VALUES ARE FOR REFERENCE ONLY.
1.
DIMENSIONS ARE NOMINAL AND TOLERANCES ARE NOT IMPLIED UNLESS SPEIFICALLY STATED.
2.
REFER TO 190-01115-01 FOR ADDITIONAL PARTS LIST.
3.
