190-01115-01 G3X/G3X Touch Installation Manual - Inventory of Materials
Rev. AC Page 1-2
1.3 Optional Garmin Equipment
1.3.1 Garmin Optional LRU Installation Kits
Table 1-3 Available GDU Display Units
Item Part Number
G3X - GDU 370, 7" Portrait Non-Touch Display** 010-00667-15
G3X Touch - GDU 460, 10.6" Display 010-01057-00
G3X Touch - GDU 465, 10.6" Display with SXM Receiver 010-01057-10
G3X Touch - GDU 470, 7" Portrait Display 010-01765-00
G3X Touch - GDU 450, 7" Landscape Display 010-01056-00
G3X Touch - GDU 455, 7” Landscape Display with SXM Receiver 010-01056-10
*Any combination of G3X Touch displays can be installed in a single system (maximum of four displays)
**Not compatible with G3X Touch displays
Table 1-4 LRU Connector/Installation Kits
LRU
Connector/Installation
Kit Part Number
Installation Kit
Included with LRU?
GAD 27 Flaps/Lights/Trim
Controller
011-03877-00 (Table 3-2) N
GAD 29 ARINC 429 Adapter 011-03271-00 (Table 4-2) N
GAP 26 Air Data Probe N/A N
GDU 37X Display 011-01921-00 (Table 6-1) Y
GDU 45X Display 010-12150-01 (Table 7-1) N
GDU 46X Display 010-12150-00 (Table 8-1) N
GDU 470 Display 010-12150-02 (Table 9-1) N
GDL 39R (9 Pin Connector) 010-11825-20 (Table 1-6) N
GDL 5XR Data Link 010-12498-60 (Table 1-6) N
GEA 24 EIS 011-02886-00 (Table 10-2) N
GMC 305 Mode Controller 010-12034-00 (Table 12-2) N
GMC 307 Mode Controller 010-12421-00 (Table 13-2) N
GMU 11 Magnetometer 011-04349-90, Install Kit (Table 14-3) N
GMU 22 Magnetometer 011-00871-10, Conn Kit (Table 15-3) N
GPS 20A 011-03914-00 (Table 16-3) N
GSA 28 Servo Actuator
011-02950-00, Conn Kit (Table 17-6)
011-02950-01, 90° Conn Kit (Table 17-7
)
N
GSU 25 ADAHRS K10-00181-00, Conn Kit (Table 18-2 ) Y
GSU 73 ADAHRS/EIS NA Y
