Garmin G3X Touch Installation Manual

190-01115-01 G3X/G3X Touch Installation Manual - Engine/Airframe Sensor Installation
Rev. AC Page 23-6
23.2 Engine Sensor Applications
23.2.1 Garmin Engine Sensor Kits
Table 23-2, Table 23-3, and Table 23-4
list Garmin sensor kits available for G3X installations. Refer to
Sensor Interface drawings in Section 30
when installing Sensor Kits K00-00512-00 and K00-00513-00.
Refer to Sensor Interface drawings in Section 31
when installing Sensor Kit K00-00514-00.
Table 23-2 Contents of G3X Sensor Kit, 4 Cylinder Lycoming/Continental (K00-00512-00)
Item Garmin P/N Quantity
Fuel Flow Transducer, EI FT-60 494-10001-00 1
Oil Pressure Transducer, Powered, 150 psi, Gage, w/connector,
Kavlico P4055-150G-E4A
494-30004-00 1
Manifold Pressure Transducer, Powered, 30 psi, Absolute,
w/connector, Kavlico P4055-30A-E4A
494-30004-01 1
Type K Thermocouple, Bayonet, CHT, Alcor 86253 494-70000-00 4
Type K Thermocouple, 3/8-24 Bayonet, EGT, Alcor 86255 494-70001-00 4
RTD, Oil Temperature, UMA 1B3-2.5R 494-70004-00 1
Shunt, Ammeter, +/-50 mV, 100 amps, UMA 1C4 909-D0000-00 1
Table 23-3 Contents of G3X Sensor Kit, 6 Cylinder Lycoming/Continental (K00-00513-00)
Item Garmin P/N Quantity
Fuel Flow Transducer, EI FT-60 494-10001-00 1
Oil Pressure Transducer, Powered, 150 psi, Gage, w/connector,
Kavlico P4055-150G-E4A
494-30004-00 1
Manifold Pressure Transducer, Powered, 30 psi, Absolute,
w/connector, Kavlico P4055-30A-E4A
494-30004-01 1
Type K Thermocouple, Bayonet, CHT, Alcor 86253 494-70000-00 6
Type K Thermocouple, 3/8-24 Bayonet, EGT, Alcor 86255 494-70001-00 6
RTD, Oil Temperature, UMA 1B3-2.5R 494-70004-00 1
Shunt, Ammeter, +/-50 mV, 100 Amps, UMA 1C4 909-D0000-00 1
Table 23-4 Contents of G3X Sensor Kit, Rotax 912 (K00-00514-00)
Item Garmin P/N Quantity
G3X External Components for Rotax 912 RPM Signal (see Table 23-5) 011-02348-00 1
Manifold Pressure Transducer, Powered, 30 psi, Absolute, w/
connector, Kavlico P4055-30A-E4A
494-30004-01 1
Fuel Pressure Transducer, Powered, 15 psi, Gage, w/connector,
Kavlico P4055-15G-E4A
494-30004-03 1
Type K Thermocouple, 3/8-24 Bayonet, EGT, Alcor 86255 494-70001-00 2
Shunt, Ammeter, +/-50 mV, 100 Amps, UMA 1C4
909-D0000-00 1

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
