190-01115-01 G3X/G3X Touch Installation Manual - Engine/Airframe Sensor Installation
Rev. AC Page 23-7
23.2.2 Other Piston Engine Applications
In addition to the engines supported by Garmin sensor kits (see Section 23.2.1
) the G3X system's
engine/airframe inputs can be configured for use with a variety of other engine types.
Rotax FADEC Sensors - The G3X system is capable of monitoring the following engine parameters from
the Rotax 912iS/915iS FADEC digital interface, when connected to the dedicated FADEC CAN interface
on a GEA 24:
•RPM
• Manifold pressure
• Manifold air temperature
• Oil pressure
• Oil temperature
• Exhaust gas temperature
• Coolant temperature
•Fuel flow
• ECU bus voltage
See Figure 31-2.2
for GEA 24 to Rotax FADEC wiring information.
Use UMA N1EU70D differential sensor for fuel pressure, see Section 23.3.5.1
.
Lycoming iE2 Sensors - The G3X system is capable of monitoring the following engine parameters from
the Lycoming iE2 FADEC digital interface, when connected via a GEA 24:
•RPM
• Manifold pressure
• Oil pressure
• Oil temperature
• Exhaust gas temperature
• Cylinder head temperature
• Turbine inlet temperature
• Fuel pressure
• ECU bus voltage
Table 23-5 Contents of G3X External Components for Rotax 912 RPM Signal Kit
(011-02348-00)
Item Garmin P/N Quantity
Silicon Diode, 1A, 200V 680-00006-D0 2
7.5 V Zener Diode 682-00012-00 1
300 Resistor, 1%, 0.5 W
902-A300R-F0 2
