Garmin G3X Touch Installation Manual

190-01115-01 G3X/G3X Touch Installation Manual - GPS/XM Antenna Installation
Rev. AC Page 22-34
Figure 22-35 GA 55 Installation Drawing
3.00 76.2
2X 1.25 31.8
5.00
127.0
FORWARD
BACKING PLATE
OUTLINE
.83 [21.1]
2.59 65.8
.60 15.2
BNC CONNECTOR
FRONT VIEW
011-00134-00
ANTENNA, AVIATION,
GA 55
253-00002-00
GASKET, NEOPRENE
AIRCRAFT SKIN
ON TOP OF FUSELAGE
115-00031-00
BACKING PLATE
4X 210-10004-09
#8-32 SELF LOCKING NUT
FORWARD
.50 12.7
4.23
107.4
.22 5.6
1.91
48.5
4X #8-32 STUD
FORWARD
SIDE VIEW
1.000 25.40
2X 1.750
44.45
2X 1.625 41.28
.813
20.64
4X .188 4.78
.625
15.88
2X .89
22.6
4.23
107.4
2.59 [65.8]
MOUNTING CUTOUT
(ANTENNA OUTLINE)
GA 55 STUD MOUNT

Garmin G3X Touch Specifications

General

Power Input	10-32 VDC
Touchscreen	Yes
Built-in GPS	Yes
AHRS	Yes
Air Data Computer	Yes
Aviation Database	Yes
Terrain Awareness	Yes
Operating Temperature	-20°C to +55°C
Display Size	10.6 inches
Display Type	LCD
Connectivity	Wi-Fi, Bluetooth, USB, RS-232, CAN bus
Engine Monitoring	Yes
Autopilot Compatibility	Yes
Traffic Awareness	Yes
Weather Data	Yes
