190-01115-01 G3X/G3X Touch Installation Manual - Inventory of Materials
Rev. AC Page 1-4
1.4 Optional Garmin LRUs
Table 1-7 lists optional Garmin LRUs that can be installed with the G3X system. If any of these LRUs are
to be used in this installation, verify that all required installation materials such as connector kits have been
acquired. Installation information for LRUs not documented in this manual can be found in the Installation
Manual for each respective LRU.
Table 1-7 Optional Garmin LRUs
LRU
All Install Info Included
In This Manual?
Section
GAD 27 Flaps/Lights/Trim Controller Yes Section 3
GAD 29 ARINC 429 Adapter Yes Section 4
GAP 26 Air Data Probe Yes Section 5
GDL 39/GDL 39R Data Link No NA
GDL 5XR Data Link No NA
GDU 37X* Display
(if installing more than one)
Yes Section 6
GDU 45X* Display
(if installing more than one)
Yes Section 7
GDU 46X* Display
(if installing more than one)
Yes Section 8
GDU 470* Display
(if installing more than one)
Yes Section 9
GEA 24 EIS Yes Section 10
GI 260 Yes Section 11
GMC 305 Mode Controller Yes Section 12
GMC 307 Mode Controller Yes Section 13
GMU 11 Magnetometer Yes Section 14
GNS 400/500 Series Units No NA
GNS 480 GPS/Comm Navigator No NA
GSA 28 Servo Actuator Yes Section 17
GSU 25** ADAHRS Yes Section 18
GSU 73** ADAHRS/EIS Yes Section 19
GTN 600/700 Series Units No NA
GTR 20 Yes Section 21
GTR 200 No NA
GTX Transponder No NA
SL30 Nav/Comm Transceiver No NA
SL40 Comm Transceiver No NA
*One GDU 37X or one GDU 4XX are required
**One GSU 25 and/or GSU 73 is required
