Garmin G3X Touch Installation Manual

190-01115-01 G3X/G3X Touch Installation Manual - GSU 73 Installation
Rev. AC Page 19-7
19.5 Outline and Installation Drawings
Figure 19-4 GSU 73 Outline Drawing
2.8 71
1.8 46
3.2 81
4.46 113.2
NOTES:
DIMENSIONS: INCHES[mm].
1.
DIMENSIONS ARE SHOWN FOR REFERENCE ONLY.
2.
MOUNTING HOLES FOR #10 PAN HEAD OR HEX HEAD FASTENERS.3.
CENTER OF GRAVITY LOCATION INCLUDES UNIT WITH CONNECTOR KITS.
4.
186.2
139.8
5.50
2X
2X 7.33
1.45 36.7
PITOT AIR FITTING
1/8-27 ANPT FEMALE THREAD 1/8-27 ANPT FEMALE THREAD
P732
STATIC AIR FITTING
P731
49.8
3.96
1.96
2X
100.6
22.1
29.71.17
.87
TYP
5.50 139.7
SEE NOTE 3
.210 5.33
.40
.25
6.4
.65 16.6
127.05.002X
4.50
4X
114.3
10.2
2X
4.25 108.0
GSU 73 UNIT 011-01817-00
P731 CONNECTOR KIT 011-01818-00
P732 CONNECTOR KIT
011-01818-01
CONFIGURATION MODULE KIT
(NOT SHOWN)
011-00979-20
THERMOCOUPLE KIT
(NOT SHOWN)
011-00981-00
