190-01115-01 G3X/G3X Touch Installation Manual - Inventory of Materials

Rev. AC Page 1-3

1.3.2 GPS/XM Antenna(s)

A Garmin or non-Garmin GPS antenna is required for a G3X installation. A Garmin or non-Garmin XM

antenna is required for G3X installations using SiriusXM® weather. See Section 22

for required materials

for antenna installation including mounting brackets, doubler plates, rivets, hardware, cables, connectors,

and sealant.

GTP 59 Temperature Probe 011-00978-00 (Table 20-2) Y

GTR 20 011-03241-00 (Table 21-3) Y

Garmin GPS and/or XM Antennas NA N

Table 1-5 Contents of GDL 39R Connector Kit (010-11825-20)

Item Part Number Quantity

Backshell w/Hdw, Jackscrew, 9/15 pin 011-01855-00 1

Conn, Receptacle, d-Sub, Crimp Socket, Commercial,

9 CKT

330-00625-09

Contact, Sckt, Mil Crimp, size 20, 20-24 AWG 336-00022-02 9

Table 1-6 Contents of GDL 5XR Connector Kit (010-12498-60)

Item Part Number Quantity

Backshell w/Hdw, Jackscrew, 15/26 pin 011-01855-01 1

Conn, Receptacle, d-Sub, Crimp Socket, Commercial,

15 CKT

330-00625-15

Contact, Sckt, Mil Crimp, size 20, 20-24 AWG 336-00022-02 16

Table 1-4 LRU Connector/Installation Kits

LRU

Connector/Installation

Kit Part Number

Installation Kit

Included with LRU?
