Garmin G3X Touch - Outline and Installation Drawings

190-01115-01 G3X/G3X Touch Installation Manual - GAD 27 Installation
Rev. AC Page 3-4
3.6 Outline and Installation Drawings
Figure 3-2 GAD 27 Outline Drawing
3.780 96.01
5.204
132.18
.100 2.54
.040 1.02
TYPICAL THICKNESS
BENEATH FASTENER HEAD
3.569 90.65
4.687
119.05
1.723 43.77
3.215 81.66
CENTER OF GRAVITY
.984
24.99
CENTER OF GRAVITY
3.000 76.20
6.533
165.93
.390 9.91
4.650 118.11
.277 7.04
1.831 46.51
CENTER OF GRAVITY
NOTES:
DIMENSIONS: INCHES [MM].
1.
DIMENSIONS ARE SHOWN FOR REFERENCE ONLY. 2.
