190-01115-01 G3X/G3X Touch Installation Manual - Engine/Airframe Sensor Installation
Rev. AC Page 23-1
23 ENGINE/AIRFRAME SENSOR INSTALLATION
23.1 Engine/Airframe Sensor Options
Table 23-1 lists the types of engine/airframe sensors that may be used for the various engine/airframe
inputs. Many of these sensors are included in the Garmin G3X Sensor Kits (Section 23.2
). Each of the
sensors must be correctly installed and configured (Section 33.4.19
for GDU 37X systems and
Section 34.4.26
for GDU 4XX systems) prior to use.
In addition to the engine sensors listed in Table 23-1, the G3X system can also work with
many other sensors (not listed) that output a compatible signal, refer to the sensor
specifications to determine compatibility.
Table 23-1 Compatible Engine/Airframe Input Sensors
SENSOR TYPE
COMPATIBLE
SENSORS
GARMIN PART
NUMBER*
NOTES
Bus Voltage
10-29 Vdc input N/A
Amploc KEY100 Hall
effect sensor
N/A +/- 100 A
UMA 1C4 shunt 909-D0000-00 +/- 100 A
Other ammeter shunt or
Hall effect sensor types
N/A
Uses custom user-defined
calibration (millivolts to amps)
Carburetor
Temperature
Rotax 965531 N/A
Rotax 966385 N/A
50-150C Thermistor
(e.g. VDO 320-XXX
series)
N/A
UMA 1B10R RTD 494-70005-00
UMA temperature sensors without
the "R" designation are not
compatible
Coolant Pressure
Kavlico P4055-50G-E4A 494-30004-02 0-50 psiG
Any voltage-output
pressure transducer
N/A
Uses custom user-defined
calibration (voltage to pressure)
Custom Analog
Parameter
Any voltage-output
sensor
N/A
Uses custom user-defined sensor
calibration
*Items with a Garmin part number may be included in a G3X Sensor Kit (Section 23.2), and are
available individually from Garmin Dealers
