You display the assignment table for the send priority with the show qos cos-remap
command.
10.5.3.10 dscp-map
Description
With this command, you configure the assignment of DSCP priorities to queues.
Requirement
You are in the QOS configuration mode.
The command prompt is as follows:
cli(config-qos)#
Syntax
Call up the command with the following parameters:
dscp-map <dscp (0-63)> queue <queue(1-4)>
The parameters have the following meaning:
Parameter Description Range of values / note
dscp Priority 0 … 63
queue Keyword for a queue -
queue Queue to which this priority is assigned 1 … 4
The DSCP priorities are assigned to the queues as follows in the default setting:
● DSCP codes 0 - 15 → Queue 1
● DSCP codes 16 - 31 → Queue 2
● DSCP codes 32 - 47 → Queue 3
● DSCP codes 48 - 63 → Queue 4
Result
The assignment table for DSCP codes is configured.
Further notes
You display the current assignment table of DSCP priorities to queues with the show qos
dscp-map command.
Load control
10.5 Service classes
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
492 Configuration Manual, 07/2017, C79000-G8976-C361-06
