Set Up and Maintenance
128 9836 3521 01
4.4.1.3 Bolt node
Select a Bolt node to display the most common properties of the Bolt.
Use the Name field to change the name of the Bolt. This name will identify the Bolt in cycle data reports,
etc. and may be up to 20 characters long.
The number entered in the Bolt number field may be used as a more compact identifier of bolt (in
addition to its name). This number may be included in the reports as the variable "Bolt No" (see Bolt level
result variables). The number must be unique within the station and within the range [1..9999].
With Bolt Status combo box you can control whether or not the bolt is connected, i.e. used by the system,
or disconnected. In the latter case you can also chose if it should be reported as OK or NOK.
Bolt type is a free text that identifies the type of the bolt. This information is used for the result variables
Total Type, Total Type OK and Total Type NOK, see chapter: Bolt level result variables.
Use the Spindle combo box to select the default spindle to use to tighten the bolt. Note that this is only
the default selection. A bolt may use different spindles in different modes. See chapter: The Mode Table
form for how to configure this.
Specify to which reject management group, or groups, the bolt belongs using the RM Group field. Enter
comma separated numbers (1, 3, 5), or intervals (1-5). See "Group" in chapter: Glossary for a definition
and Step – Rejects for how it is used.
4.4.1.4 Programs node
Clicking on the Programs node will in fold/unfold a list all programs defined in the system.
