System Architecture
26 9836 3521 01
2.3 Hardware Structure
The figure below describes the hardware structure of a PowerMACS 4000 system, i.e. how hardware
components are used.
Digital I/O Sp 1 Sp 2..
............
TC 1 (primary) TC 2 (secondary) ...... TC n (secondary)
..Sp n
Factory
Network
Ethernet
Field bus
Serial bus
I/O bus
Hub
Router
I/O-module
Peripheral
Peripheral
Console with ToolsTalk
