Basic Functions
64 9836 3521 01
3.6.3 View Cycle Data
The Cycle Data window is used to display data from the tightening cycles.
The display shows the last cycle. When new cycles are added older cycles are scrolled upwards. By use
of the vertical scrollbar you can go back to earlier cycles. If the text is wider than the window, a horisontal
scrollbar appears.
If you press Hold the display is temporarily stopped. Cycle data are still recorded and when you release
the Hold by pressing the Hold button again the presentation will continue. Press Clear to clear the list.
Press Refresh to clear the list and retrieve all cycle data stored on the System TC.
If the Advanced button is pressed you can specify the format settings by pressing the Layout button, if
you want to present just specific cycles press the Settings button, the following frame will then appear
below the cycle data window:
Here you can specify if you want to present OK and/or NOK cycles, for specific stations and/or tightening
programs, or cycles with specific errors.
In the ID field write as many characters you like. All cycles that have an ID that contains the string of
characters will be displayed.
You can also present cycles between certain times, e.g. 99-12-31, 23:59..00-01-01, 00:01. Enter date and
time in the format your computer is set up for. Use “..” as separator between start and stop times. If you do
not enter any date, today is assumed. If you do not enter any time, start time is assumed to be 00:00 and
stop time 23:59.
