Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
9836 3521 01 449
8.11.1.4 TC Result Record Formats
Parameter
Id
Bytes
Implementation
Number of
spindles
01
2
The number of spindles is two bytes long and specified by 2 ASCII digits.
Reports number of bolts in the cycledata. For PowerMACS 0 and 1 are
possible numbers. In the case of 0 bolts in the cycledata the spindle specific
part is omited (18 x 0 = 0).
VIN Number
02
25
The VIN number is 25 byte long and is specified by 25 ASCII characters
taken between 0x20 and 0x7F Hex. Reports Id string (CD_ST_IDDEV).
Job Number
03
2
The job number is two bytes long and always 00 as no such number is
available in PowerMACS.
Pset number
04
3
This is the pset number that is run (psetId). The pset number is three byte
long specifying a range of 000 to 999 and is specified by three ASCII digits
(„0‟….‟9‟). Reports mode number.
Batch Size
05
4
The batch size is four byte long and always 0000 as no such number is
available in PowerMACS.
Batch
counter
06
4
The batch counter number is four byte long and always 0000 as no such
number is available in PowerMACS.
Batch status
07
1
The batch status is specified by one ASCII character. Always 0 as no such
number is available in PowerMACS.
Torque Min
limit
08
6
The torque min limit is multiplied by 100 and sent as an integer (2 decimals
truncated). The torque min limit is six byte long and is specified by six ASCII
digits („0‟….‟9‟).
Bolt T, Min limit, from the Monitor function.
Value retrieved from the first bolt reported in the cycle data. Reports
measured value in global torque unit times 100.
Torque Max
limit
09
6
Reports Bolt T, Max limit, from the Monitor function. Same format as Torque
Min limit is reported in.
Torque final
target
10
6
Bolt T from the Monitor function, which is the measured final torque in the
monitor function. Same format as Torque Min limit is reported in.
Angle Min
11
5
The angle min value has a specified range between 0 and 99999. The angle
min value is five byte long and is specified by five ASCII digits („0‟….‟9‟). Bolt
A, Min limit, from the Monitor function. The value is retrieved from the first bolt
reported in the cycle data
Angle Max
12
5
Bolt A, Max limit, from the Monitor function. Same format as Angle Min limit is
reported in.
Final Angle
Target
13
5
Bolt A from the Monitor function, which is the measured angle in the
monitoring function. Same format as Angle Min limit is reported in.
Date/time of
last change
in Pset
settings
14
19
Time stamp for the last change in the current program or time for latest
complete download. The time stamp is 19 byte long and is specified by 19
ASCII characters (YYYY-MM-DD:HH:MM:SS).
