Tightening
294 9836 3521 01
Function: Waits until the specified stop condition is fulfilled. Does not run the spindle while waiting.
The step waits the specified time
The step waits until a positive edge of one
of the PLC Station Variables START or
INTERMEDSTART is detected
Digital input.
Local DI 1, … Local DI 4
PLC_DI_1, … PLC_DI_10
DI Spindle def.
Stop Condition:
Falling Edge, Rising Edge,
Any Edge, Low or High
The step waits until the selected digital
signal fulfils the condition selected in Stop
Condition
The step waits until all other bolts running in
parallel have reached the next
synchronization point.
If the check box Hold Position is checked, the spindle tries to hold the position of the bolt
during the wait. The position will be held until the next step starts, if there are any delays
between the steps due to synchronization the position will still be kept.
6.5.2.22 TA – Run Torque-Angle with no stop
Step type Id: 28
Parameters: Torque TC, Angle, TA step type, Falling edge,
A start cond, Angle torque start, DIR (Direction).
Function: Depending on the value of parameter TA step type four different functions are possible.
The TA program is considered to be one step, as there is no step change where the
spindles can be synchronized. The Angle parameter may be reported using an angle check.
