2.3.1.3 The TC HMI Menu System
The TC HMI menu system provides a flexible and intuitive interface to configure and interact with
individual TCs. The TC HMI also show the status for certain operations, these include downloading of
software, copying or restoring the setup from System TC to a Spindle TC and possible version conflicts
detected in the system.
Default Menu
The default menu contains two view items, you can select which view by pressing the up/down buttons
(the two middle soft buttons). Press the Setup button to go to the Setup menu and the Info button to go to
the information menu.
TC 01
Setup Info
T: 120.32
A: 245.21
Setup Info
Default view
Shows TC Number (Last
digits of internal IP address)
Torque view
Shows last measured Bolt T
and Bolt A
The torque and angle values shown are collected from the monitoring buffer – select the monitoring buffer
to use by adjusting the properties on the TC in the System Map, see chapter:
