Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
9836 3521 01 475
Field
Bytes
Value sent
Number of
Characteristics
2
Characteristic Data
Field
Bytes
Value sent
Identification
5
See table below for possible values
Unit
10
Length
1
Factor
2
Algebraic Sign
1
Increment
8
Start Value
8
Actual Value
8
The result variable
Step
2
Always 1
Number of Parameters
2
For every
parameter
Id
6
See table below for possible values
Value
8
The value
8.11.5.2 Value sent as Maintenance Sequence (AFO-number)
The value sent in the field Maintenance Sequence is built up using the following result variables:
Station name
Spindle number
Bolt number
Program number
The layout of the maintenance sequence is controlled by the settings in the I-P.M. reporter.
The station name is put first in the maintenance sequence; the value of the field width in the reporter sets
the number of characters to use. If width is empty the whole station name is used as it is.
After the station name the spindle number and bolt number are sent if they are selected in the reporter.
The one that has the lowest order value selected in the reporter are sent first. They are added directly
after the station name without any additional characters in-between
Last in the maintenance sequence the program number is sent, if it is selected in the reporter. Between
the spindle number/bolt number and the program number the character „-„ is added. This character is only
added if a program number is sent. If the program that was used didn‟t have a program number specified,
the number 0 is used.
