Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
9836 3521 01 457
8.11.4.1 Parameters for PDT
Station Type - There are four different station types, SAW/WIS, SPS, VBA and SSE. Controls the
behavior of the device. See the description of the different types below.
Barcode scanned - Possible choices are LI, PN and KN. Specifies the type of the scanned barcode.
VIN number type -Possible choices are PN or KN. Controls how "Wp ID" shall be treated when sending
cycle data to PLUS. Only possible to select if “Barcode scanned” is LI, otherwise the value is the same as
“Barcode scanned”.
Station ET -Possible choices are E and G. The value selected here is used as “Einzelergennis Typ Kz”
when sending tightening results to PLUS.
Station AB -The value to use as AB “Anlagen betreiber” for all bolts when sending cycle data to PLUS.
Will also be included in the cycle data as the result variable Station AB.
Use QO from PLC -Controls which value to use as QO when sending requests for TMU. If checked the
value is taken from the PLC, otherwise the value “QO for request of TMU” will be used.
QO for request of TMU -The value to use as QO when sending a request for a TMU to the PLUS server.
Only enabled if “Use QO from PLC” is unchecked and “Station Type” is SAW/WIS.
Listen Port -The port that PM listen to for PLUS connections. Valid port numbers are 20 000 – 32 767
PLUS IP Address -The IP address of the PLUS server to communicate with.
PLUS Port -The port in the PLUS server that PowerMACS connects to. Valid port numbers are 0 –
32 767.
