8.11.1.3 TC Status Record Formats
The number of spindles is two bytes long and specified by 2 ASCII digits.
Reports number of bolts in the cycledata. For PowerMACS 0 and 1 are
possible numbers. In the case of 0 bolts in the cycledata the spindle specific
part is omited (18 x 0 = 0).
The sync tightening Id is a unique Id for each sync tightening result.
Each individual result of each spindle is stamped with this Id.
The tightening Id is incremented after each sync tightening. 5 ASCII digits.
Max 65 535. Reports Station DataNo, created when cycle is ready.
Reports station status. The sync overall status is specified by one ASCII digit
1 = OK or OKR, 0 = NOK, TERMNOK or NOKRM.
Bytes 1-2: Ordinal bolt number (01 –99)
Bytes 3-4: Spindle number (01-99)
Byte 5: Reports 0 when bolt status is NOK, NOKRM or TERMNOK . Reports
1 when bolt status is OK or OKR.
