8.11.4.9 TC Result Formats for PDT
The tightening results are reported to PLUS according to the specification.
Station data:
Field
Implementation
QUALITÄTSAUSSAGE-ORTS-NR
QO
Station QO in the cycle data.
JOB-NR
JN
Mode number for the tightening.
GESAMT-Q-AUSSAGE
GQ
Station status of a tightening.
1 = OK is sent for status OK and OKR (OK after repair)
0 = NOK is sent for status NOK and TERMNOK (failed
during termination).
GESAMT-STATUS
GS
Always 0
SOLL-ANZAHL-EINZELERGEBNISSE
SA
Station SA in the cycle data.
EINZELERGEBNIS-TYP-KZ
ET
The value in Station ET.
Bolt data:
Field
Implementation
EINZELERGEBNIS-NR
EN
Bolt number from ToolsTalk PowerMACS setup.
EINZELERGEBNIS-IDENT
EI
Bolt name from ToolsTalk PowerMACS setup. The bolt
number will be added at the end of the bolt name to reach 24
characters.
EINZELERGEBNIS-Q-AUSSAGE
EQ
Bolt status for this tightening
1 = OK is sent for status OK and OKR (OK after repair)
0 = NOK is sent for status NOK, TERMNOK (failed during
termination) and NOKRM (not successful due to reject
management)
EINZELERGEBNIS-STATUS
ES
Always 0
EINZELERGEBNIS-QA-DETAIL
ED
Customer Error Code in the cycle data.
ANLAGEN-ORTS-NR
AO
Will always be the same as QO for all bolts.
ANLAGEN-BETREIBER
AB
Station AB in the cycle data, always the same for all bolts.
USER-ID
US
Id Res 4 in the cycle data, always the same for all bolts.
