8.11.1.2 Supported message types
Implementation description
Communication start acknowledge
Parameter set numbers upload request
Modes are used for parameter sets in PowerMACS.
Parameter set numbers upload reply
Parameter set “selected” subscribe
Creation/download time for program run by first bolt in
selected mode. Mode number not 0 in start signal gives that
mode no according to start signal is used. Mode number 0
in start signal makes the station use the mode number it has
stored. When testbolt is run mode number is reset to the
mode number used before testbolt, when the testbolt cycle
is ready.
Parameter set “selected” acknowledge
Parameter set “selected” unsubscribe
Selection of Mode. Mode number is sent to station. ModeNo
NOT_DEFINED (-32768) (test bolt not mode view) is not
reported as parameter set change and mode is reset to
original mode in station when the test bolt cycle has run.
Tool serial number (Id 01) is reported as spaces ' '.
As Tool number of tightening (Id 02) is reported the number
of cycles run on the spindle controller of the TC holding the
epHan device (max value is 2147483647).
As Last calibration date (Id 03) is reported the time for when
the service flag was last reset (cycle count changes).
Controller serial number (Id 04) is reported as spaces ' '.
Disables START signal in PLC. When the station controller
receives a START signal (from PLC or testbolt) a info event
is issued to report that the station is disabled if a Disable
tool signal has been received from the epHan device. When
a Disable tool signal is received during a cycle an
emergency stop is issued and the cycle stops. Emergency
stop event is reported.
Enables START signal in PLC. Station controller is enabled
at startup. To enable the station controller when disabled an
Enable tool signal must be sent.
