Atlas Copco PowerMACS 4000 User Manual

Peripheral Devices
470 9836 3521 01
8.11.4.10 TC Result Format for PQD
The tightening results are reported to PLUS according to the specification.
Station data:
Field
Implementation
Fertigungspunkt
FP
Station QO in the cycle data
Id-Typ
IT
The string specified as VIN number type
Id-Wert
IW
Wp. Id. In the cycle data
Q-AUSSAGE-ART
AA
Always „SC‟
Bolt data:
Field
Implementation
Q-AUSSAGE-IDENT
QI
Bolt Id from WinTC setup
Q-AUSSAGE
QA
Bolt status for this tightening
IO = OK is sent for status OK and OKR (OK after repair)
NIO = NOK is sent for status NOK, TERMNOK (failed during
termination) and NOKRM (not successful due to reject
management)
FEHLERCODE-ANLAGE
FE
Customer Error Code in the cycle data
Q-AUSSAGE-STATUS
QS
Always 00
USER-ID
US
Id Res 4 in the cycle data, always the same for all bolts.
