Peripheral Devices
472 9836 3521 01
Only sent if limits for SO T is selected in the reporter
This value is not possible to send.
The time that the step was run, measured by the Check
time check. Only sent if Time is selected in the reporter
The step number for the step that produced the other data
Not sent, the current is used as redundancy torque, RM,
instead.
The value produced by the Gradient Restriction. Only sent if
Grad is selected in the reporter
8.11.4.11 Selecting the data to report
Only one angle value and one torque value can be sent for each tightening. Bolt T and Bolt A are reported
in OK cycles and SO T and A (from the failing step) in NOK cycles.
If Bolt level data is reported but both Bolt T and Bolt A are empty the step data for the last step with both
SO T and A is reported instead.
8.11.4.12 Selecting the data to report
Only one angle value and one torque value can be sent for each tightening. Bolt T and Bolt A are reported
in OK cycles and SO T and A (from the failing step) in NOK cycles.
If Bolt level data is reported but both Bolt T and Bolt A are empty the step data for the last step with both
SO T and A is reported instead.
