Tightening
382 9836 3521 01
6.7 Result variables
This chapter describes which system data and tightening results that are available for reporting to the
different devices in the system.
What data to report to a particular device is configured using a Reporter. How to create and configure
reporters is described in the chapter: Reporter.
The result data is divided in the following sections
Station level data
Bolt level data
Step level data
If a result variable for some reason does not have a value, e.g. due to that the check that produces the
value is not included in the program, then the value NOT_DEFINED is reported for it.
A NOT_DEFINED value is printed as blanks (spaces) when reported as text and the value –32768 when
reported in binary format.
6.7.1 Statuses
Stations and bolts have a variable named "Status" that indicates their resulting status.
The Station Status variable can take one of the following values:
Successful. No repairs have been made.
Successful. Errors have occurred but have been repaired
Not successful. Either a fatal error has occurred or a bolt failed to repair a
repairable error.
Not successful. An error occurred while running a terminate sequence (i.e. the
steps specified using “Terminate with step” on the Reject tab for a step). The
execution of steps was terminated when the error was found
