Peripheral Devices
614 9836 3521 01
True if external equipment inverses direction.
External Equipment GearRatio
Torque Measurement Loss factor for transducers, < 1.0
External Equipment Replacement WindUp for Angle
Channel 1.
External Equipment Replacement WindUp for Angle
Channel 2.
Example: Spindle[1].Direction
8.17.5.3 Spindle, Channel data
Syntax: Spindle[<spindle no>].Chan[<channel no>].<parameter>
<spindle no> = 1..Max spindle no
<channel no> = Channel number, 1..6 (number is given by the order in the form)
<parameter> = See table below (and Spindle Set Up for a description)
Filter frequency (for the torque and current channels)
Example: Spindle[1].Chan[1].Filter
