REPLACEMENT AND ADJUSTMENT
SM 9 B660
Z-Folding Unit
B660
3.7 LOWER STOPPER MOTOR/HP SENSOR, RELAY
BOARD
Front cover ( 3.2)
[A]: Lower stopper motor bracket ( x 3,  x 1)
[B]: Lower stopper HP sensor ( x 1)
[C]: Lower stopper motor ( x 2,  x 1,  x 1)
[D]: Relay board ( x 4,  x 3,  x 10)
B660R106.WMF
[A]
[B]
[C]
[D]
