INPUT/OUTPUT CHECK
B064 Series/B140 Series/G126 5-174 SM
5.7.6 FINISHER OUTPUT CHECK: SP6118
No. Description
1 Upper Transport Motor
2 Shift Tray Exit Motor
3 Upper Tray Junction Gate Solenoid
4 Shift Tray Lift Motor
5 Jogger Motor
6 Stapler Motor
7 Staple Hammer Motor (Stapler Unit)
8 Punch Motor
9 Stapler Junction Gate Solenoid
10 Positioning Roller Solenoid
11 Stack Feed-out Motor
12 Shift Motor
13 Stapler Rotation Motor
14 Lower Transport Motor
15 Exit Guide Motor
16 Stack Plate-Center Motor
17 Pre-stack Junction Gate Solenoid
18 Pre-stack Paper Stopper Solenoid
19 Stapler Return Solenoid
20 Stack Plate- Front Motor
21 Stack Plate – Rear Motor
22 Stacking Roller Drag Motor
23 Stacking Roller Motor
24 Shift Jogger Motor (Optional Jogger Unit)
25 Shift Jogger Lift Motor (Optional Jogger Unit)
