TEST PATTERN PRINTING
B064 Series/B140 Series/G126 5-10 SM
Test Pattern Table
These patterns can be selected for SP2902-003
No. Test Pattern
0 None
1 Alternating Dot Pattern (1-dot)
2 Alternating Dot Pattern (2-dot)
3 Alternating Dot Pattern (4-dot)
4 Alternating Dot Pattern (1024-dot)
5 Grid Pattern (1-dot): 0ch
6 Grid Pattern (1-dot): 1ch
7 Grid Pattern (1-dot): 2ch
8 Grid Pattern (1-dot): 3ch
9 Grid Pattern (1-dot pair)
10 Checkered Flag Pattern
11 Horizontal Line (2-dot)
12 Vertical Line (2-dot)
13 Horizontal Line (1-dot)
14 Vertical Line (1-dot)
15 Cross Stitch (Horizontal)
16 Cross Stitch (Vertical)
17 Argyle Pattern
18 Trimming Area
19 Full Dot Pattern
20 Black Band (Vertical)
21 Black Band (Horizontal)
22 Stair
23 Blank Image
24 Grid Pattern (1-dot): 0ch (with external data)
25 Trimming Area (with external data)
26 Argyle Pattern (with external data)
27 Outside Data
