DEVELOPMENT AND TONER SUPPLY
B064 Series/B140 Series/G126 6-72 SM
6.9.9 TONER BOTTLE SUPPLY AND VENTILATION
The toner supply motor [A] (a dc motor) and gears [B] rotate the toner bottle [C].
The toner cooling fan [D] (below the operation panel) ventilates the area around the
bottle. This fan always switches off and on with the polygonal mirror motor.
B140D955.WMF
B140D956.WMF
[D]
[A]
[B]
[C]
