REPLACEMENT AND ADJUSTMENT
SM 13 B660
Z-Folding Unit
B660
3.11 MAIN CONTROL BOARD
1. Remove the rear cover. ( 3.2)
2. Remove the main control board [A] ( x 4, x 10)
B660R111.WMF
[A]
