PAPER FEED
SM 3-95 B064 Series/B140 Series/G126
Replacement
Adjustment
3.11.2 REAR FENCE RETURN SENSOR REPLACEMENT
Turn off the main switch.
Pull out the tandem feed tray.
[A]: Rear bottom plate ( x 1)
[B]: Return sensor ( x 1).
B140R824.WMF
[A]
[B]
