DUPLEX UNIT
SM 3-89 B064 Series/B140 Series/G126
Replacement
Adjustment
3.10.6 DUPLEX ENTRANCE SENSOR
[A]: Bracket ( x 2)
[B]: Duplex entrance sensor ( x 1)
• At re-assembly, insert the plunger into the solenoid before re-attaching the
solenoid.
B140R815.WMF
[A]
[B]
