POSITIONING ROLLER
B468/B469/B674 2 SM
1.2 POSITIONING ROLLER
Open the front door.
[A]: Pull out the jogger unit.
[B]: Positioning roller ( x 1)
[C]: Positioning roller drive belt
1.3 INNER COVER
[A]: Inner cover ( x 3)
[B]: Pull out the jogger unit.
B468R003.WMF
B468R004.WMF
[A]
[B]
[B]
[C]
[A]
