B140 SERIES AND G126 SERVICE MODE
B064 Series/B140 Series/G126 4-66 SM
4.3.4 JAM CODES (B140 SERIES AND G126)
Here are lists of SC codes that are printed in the SMC report; they do not appear
on the operation panel display.
Main Unit: Paper Jam Errors
No. Check-In Failure
(Paper Does Not Arrive)
No. Check-Out Failure
(Paper Remains)
1 Initial Jam (Power On)
3 Tray 1 feed sensor 53 Tray 1 feed sensor
4 Tray 2 feed sensor 54 Tray 2 feed sensor
5 Tray 3 feed sensor 55 Tray 3 feed sensor
6 Tray 4 feed sensor (Japan Only) 56 Tray 4 feed sensor (Japan Only)
7 LCT feed sensor 57 LCT feed sensor
8 Transport sensor 1 58 Transport sensor 1
9 Transport sensor 2 59 Transport sensor 2
10 Transport sensor 3 60 Transport sensor 3
11 Transport sensor 4 (Japan Only) 61 Transport sensor 4 (Japan Only)
12 Relay sensor 62 Relay sensor
13 Registration sensor 63 Registration sensor
14 Fusing exit sensor
15 Exit unit entrance sensor
16 Exit unit 66 Exit unit
19 Exit unit entrance sensor 69 Exit unit entrance sensor
20 Duplex transport sensor 1
21 Duplex transport sensor 2 71 Duplex transport sensor 2
22 Duplex transport sensor 3 72 Duplex transport sensor 3
23 Duplex inverter sensor 73 Duplex inverter sensor
24 1-Bin tray (Japan Only) 74 1-Bin tray (Japan Only)
34 Bypass paper end sensor
NOTE: For fusing-system SC Codes, it may be necessary to reference “Jam
Codes (B064 Series)” in this manual.
Rev. 05/2005
