DIP SWITCHES
SM 5-193 B064 Series/B140 Series/G126
Service
Tables
5.10.2 CONTROLLER BOARD
Controller Board DIP SW 4
No. Function Default Comments
1 Not used OFF
2 Boot mode ON ON: Quick Boot, OFF: Normal Boot
Note: The boot time is longer when this switch is OFF
because the machine performs a full system check.
3 Not Used OFF
4 Not Used OFF
5 * Boot Selection OFF Flash ROM Boot: 5, 6, 7/ OFF, OFF, OFF
6 * Boot Selection OFF SD Card 1 Boot: 5, 6, 7/ OFF, ON, OFF
7 * Boot Selection OFF SD Card 2 Boot: 5, 6, 7/ ON, ON, OFF
SD Card 3 Boot: 5, 6, 7/ OFF, OFF, ON
8 Not Used OFF
* Dips 5, 6, &7 are for factory use only.
Controller Board DIP SW 5
No. Function Default Comments
1
D
D
F
F
U
U
OFF
2 Not Used OFF
D
D
F
F
U
U: Design, Factory Use only. Do not change these settings.
Controller Board DIP SW 6
No. Function Default Comments
1 Not Used OFF
2 Not Used OFF
3 Not Used OFF
4 Not Used OFF
Rev. 06/2005
