Ricoh Aficio 2075 SP User Manual

PCBS AND HDD
B064/B140 Series/G126 3-122 SM
3.12.5 PSU, PFC BOARDS
B064 Series
Rear lower cover ( 3.3.5)
[A]: Harness clamps ( x 3)
[B]: PSU ( x 6,  x 13)
• The PSU consists of two PCB’s.
[C]: PFC ( x 4,  x 14)
B140 Series PSU
Rear covers (3.3.5)
Controller box cover ( x 12)
[A]: PSU ( x 5,  x 7)
B140R862.WMF
B140R703.WMF
[A]
[C]
[B]
[A]
