PICK-UP/FEED/SEPARATION ROLLERS
B473 2 SM
1.2 PICK-UP/FEED/SEPARATION ROLLERS
[A]: Open the transport cover
[B]: Bracket cover ( x 2)
[C]: Pick-up roller ( x 1)
[D]: Feed roller ( x 1)
[E]: Separation roller ( x 1)
B473R002.WMF
B473R003.WMF
[C]
[D]
[E]
[B]
[A]
