REPLACEMENT AND ADJUSTMENT
SM 7 B478/B513/B531
Finisher/
Jogger Unit/
Punch Unit
B478/B513/
B531
3.2.2 POSITIONING ROLLER
1. Open the front door.
2. Remove the snap ring [A].
3. Release the rubber belt [B].
4. Replace the positioning roller [C].
B478R506.WMF
[A]
[B]
[C]
