ADF (B140 SERIES/B064 SERIES ONLY)
B064 Series/B140 Series/G126 6-20 SM
6.4.8 ORIGINAL SIZE DETECTION
[A]: Original width sensor 1
[B]: Original width sensor 2
[C]: Original width sensor 3
[D]: Original width sensor 4
[E]: B5 length sensor
[F]: A4 length sensor
[G]: LG length sensor
When the leading edge of the paper passes the skew correction sensor, the CPU
reads the outputs from the original width and length sensors.
Please refer to the table on the next page.
B140D914.WMF
[A]
[B]
[C]
[D]
[E]
[F]
[G]
