ADF (B140 SERIES/B064 SERIES)
B064/B140 Series/G126 3-132 SM
3.13.5 REGISTRATION SENSOR
Open the feed cover.
Feed unit (3.11.8)
[A]: Guide plate ( x 3)
[B]: Registration sensor bracket ( x 1)
[C]: Registration sensor ( x 1)
B140R871.WMF
B140R872.WMF
[A]
[B]
[C]
