PAPER FEED
SM 3-93 B064 Series/B140 Series/G126
Replacement
Adjustment
3.11 PAPER FEED
3.11.1 PAPER TRAY REMOVAL
1. Open the front door.
2. Pull out the tandem tray drawer [A] completely to separate the left [B] and right
[C] sides of the tandem tray.
3. Remove the left tandem tray [D] ( x 5).
B140R820.WMF
B140R821.WMF
[A]
[B]
[C]
[D]
