PAPER FEED
SM 3-107 B064 Series/B140 Series/G126
Replacement
Adjustment
3.11.10 RELAY SENSOR
[A]: Remove the LCT entrance guide cover.
[B]: Relay sensor bracket ( x 1)
[C]: Relay sensor ( x 1)
B140R843.WMF
[A]
[B]
[C]
