DETAILS
SM 25 B660
Z-Folding Unit
B660
6.4 DRIVE LAYOUT
1. Feed Motor
2. Feed Rollers
3. Fold Roller Motor
4. Lower Exit Rollers
5. Grip Rollers
6. 3rd Fold Roller
7. 2nd Fold Roller
8. 1st Fold Roller
9. Vertical Feed Rollers – 1
10. Vertical Feed Rollers – 2
11. Vertical Feed Rollers – 3
12. Vertical Feed Rollers – 4
13. Upper Exit Rollers
B660D103.WMF
1
2
3
9
4
10
11
12
13
5678
