ADF (B140 SERIES/B064 SERIES ONLY)
B064 Series/B140 Series/G126 6-16 SM
6.4.5 ORIGINAL SEPARATION
[A]: Pick-up roller
[B]: Feed belt
[C]: Separation roller
This mechanism prevents feeding more than one sheet at a time.
( Handling Paper> Handling Originals> Document Feed> FRR with Feed Belt)
B140D911.WMF
[A]
[B]
[C]
