MAIN BOARD
SM 5 B470
Cover
Interposer
Tray
B470
1.5 MAIN BOARD
Open the top cover.
Rear cover ( x 1)
[A]: Main board ( x 9, x 4)
NOTE: All DIP switch settings on the main board of the cover sheet unit should be
set to OFF.
B470R101.WMF
