ADF (B140 SERIES/B064 SERIES)
SM 3-129 B064 Series/B140 Series/G126
Replacement
Adjustment
3.13.2 FEED UNIT
1. Open the feed cover [A].
2. Remove the snap fitting [B].
3. Push the feed unit slowly to the left to disengage the shaft [C] on the right, then
lift it out.
B140R867.WMF
[A]
[B]
[C]
